XNK SPL-640 300w bsw led moving head

XNK SPL-639 300w bsw led moving head is designed for stage shows, mobile DJs, clubs, and event production. XNK SPL-639 300w bsw led moving head combines DMX control, beam effects, strobe effects, zoom functionality for dependable performance lighting and live event use. Review the technical specifications below for setup, control, and fixture details.

Input Voltage: AC 100~240V, 50/60Hz

Rated Power: 450W

Light Source System: 300W LED light source module, color temperature 8500K

Service Life: 20000 hours

Control Mode: DMX512 protocol, RDM protocol, auto-run mode, sound-activated mode, manual control mode, standalone programming control mode

Channel Mode: 2 control modes available - 16 (simplified) / 19 (standard) channels

Beam Angle: Linear zoom angle 5°-30°, linear motorized focus

Fixed Colors: 9 colors + white light, with half-color function and bidirectional rotating rainbow effect

Prism Effect: Rotating 8-facet prism disc, support bidirectional variable-speed rotation with indexing function

Fixed Patterns: 6 fixed pattern plates + white circle + flowing water effect disc, enabling self-rotation, flowing water and dithering effects

Rotating Patterns: 6 pattern plates (pluggable) + 1 water ripple pattern, supporting self-rotation, flowing water and dithering effects; pattern orientation is positionable

Frost System: Realizes soft light fogging effect, fogging angle 10-30°

Dimming System: Electronic dimming with 0～100% linear adjustment; gamma curve dimming frequency adjustable from 1.2K～25K; equipped with macro command for stable, smooth and flicker-free linear dimming

Strobe System: Electronic strobe, 0.3～25 times/second; random strobe and pulse strobe selectable

Optical System: High-definition and high-precision optical system; smooth and quiet linear motor-driven zoom for ultra-fine and smooth focus adjustment

Rotation Angle: Pan scanning 540° (16bit precision scanning); Tilt scanning 270° (16bit precision scanning). The XY axes are driven by high-speed silent 60 three-phase motors, paired with high-precision magnetic encoder positioning device for fast, quiet and high-precision scanning system; with automatic error correction reset function, pan/tilt smooth stepping control function, and pan/tilt reverse rotation function

Sleep Function: Advanced technology enables remote sleep function; the fixture automatically enters sleep mode when disconnected from signal, ensuring higher stability and safety

Display Function: 1.77-inch touch LCD screen with Chinese and English display; 180° rotatable; displays fixture and light source operating time, sensor fault information and temperature

Noise Mode: 3 noise control modes available (normal mode, low-speed mode, silent mode) for different application scenarios; noise can be linearly controlled via DMX

Heat Dissipation System: High thermal conductivity copper tube radiator; fan intelligent monitoring + intelligent temperature control algorithm, automatically adjusting fan speed according to fixture temperature; built-in overheat protection intelligent system and intelligent temperature-noise balance module

Shell Material: Flame-retardant and high-temperature resistant plastic

Power Interface: 1 power input interface, 1 power output interface

Signal Interface: 1 DMX512 input interface, 1 DMX512 output interface

Protection Grade: IP20

Working Environment: 40℃-45℃

Product Dimensions (L×W×H): 299×203×528mm

Packaging Dimensions (L×W×H): 555×405×410mm (carton)

Gross Package Weight: 15kg

Net Product Weight: 12.35kg
