XNK SPL-610 Bking prism

XNK SPL-610 Bking prism is designed for stage shows, mobile DJs, clubs, and event production. XNK SPL-610 Bking prism combines DMX control, beam effects, strobe effects for dependable performance lighting and live event use. Review the technical specifications below for setup, control, and fixture details.

Power Specifications
Input Voltage: AC 100–240V
Power Frequency: 50/60Hz
Power Consumption: 300W
Light Source & Output
Light Source: 230W
Illuminance @ 5 m: 605,000 lux
Illuminance @ 10 m: 175,000 lux
Illuminance @ 15 m: 78,000 lux
Beam Angle: 2°
Control & Effects
Dimming: 0–100% linear dimming
Strobe: 1–25 Hz (built-in multiple strobe effects)
Gobo & Color System
Gobos: 13 gobos + 1 open
Colors: 14 colors + 1 open
Prism & Optical Effects
Prism 1: 8 + 16 + 24-facet prism
Prism 2: 8-facet prism
Rainbow / Frost: Yes
Focus: Motorized focus
LED Ring Effects
Effects: Single color, color jump, color fade, multi-color flow & chasing effects
Cooling System
Cooling Fans: 5
Control Interface
DMX Channels: 16CH
Control Modes: DMX / Auto / RDM
Display: LCD display
Other Specifications
IP Rating: IP20
Max Operating Temperature: 45°C (113°F)
Pan: 630° (16-bit resolution)
Tilt: 270° (16-bit resolution)
Signal Input / Output: 3-pin XLR connectors
