PRODUCT OVERVIEW
Indoor & Outdoor LED Screen with P2.976 & P3.91 Pixel Pitch Options for High-Definition Display
Specification Indoor Outdoor Pixel Pitch P2.976 P3.91 P2.976 P3.91 LED Configuration（Kinglight) SMD1515 SMD2121 SMD1415 SMD1921 Physical Density(dots/㎡) 112896 65536 112896 65536 Module Dimension（mm) 250*250 250*250 250*250 250*250 Module Resolution 84*84 64*64 84*84 64*64 Scan Mode 1/28 1/16 1/21 1/16 Cabinet Size（mm） 1000*500 500*5...
Share the model, quantity, application and destination for a focused response.
PRODUCT DETAILS
Built for a considered specification review.
|
Specification |
Indoor |
Outdoor |
||
|
Pixel Pitch |
P2.976 |
P3.91 |
P2.976 |
P3.91 |
|
LED Configuration（Kinglight) |
SMD1515 |
SMD2121 |
SMD1415 |
SMD1921 |
|
Physical Density(dots/㎡) |
112896 |
65536 |
112896 |
65536 |
|
Module Dimension（mm) |
250*250 |
250*250 |
250*250 |
250*250 |
|
Module Resolution |
84*84 |
64*64 |
84*84 |
64*64 |
|
Scan Mode |
1/28 |
1/16 |
1/21 |
1/16 |
|
Cabinet Size（mm） |
1000*500 500*500 |
1000*500 500*500 |
1000*500 500*500 |
1000*500 500*500 |
|
Refresh Rate |
3840HZ |
3840HZ |
3840HZ |
3840HZ |
|
Brightness（㎡） |
≥800 |
≥800 |
≥5000 |
≥5000 |
|
Avg.Power Consumption |
200w/㎡ |
200w/㎡ |
280w/㎡ |
280w/㎡ |
|
MAX.Power Consumption |
640w/㎡ |
640w/㎡ |
680w/㎡ |
680w/㎡ |
|
View Angle |
1600/1600(50% birghtness) |
1600/1600(50% birghtness) |
1600/1600(50% birghtness) |
1600/1600(50% birghtness) |
|
Working Temperature |
-20℃~60℃
|
-20℃~60℃
|
-20℃~60℃
|
-20℃~60℃
|
|
Input Voltage |
AC100~240V |
AC100~240V |
AC100~240V |
AC100~240V |
|
Life Span |
100,000hrs |
100,000hrs |
100,000hrs |
100,000hrs |
KEY SPECIFICATIONS
Reference information
- Brand
- XNK Stage Lighting
